UB-200
UHF boundary microphone
Gallery:
Details & Specifications:
Home / Audio Equipment / Microphones / UB-200 UHF Boundary Microphone
- Electret boundary microphone with UHF pilot tone technology (PLL)
- 2 license-free frequency ranges: 823-832 MHz (Duplex Gap) and 863-865 MHz
- Parallel operation of up to 9 transmitters is possible without any interference
- Suitable for the WAM-400 automatic mixer
- Infrared interface for easy and error-free synchronization with the receiver via infrared signal
- Operation range with line of sight approx. 60 meters
- LCD for battery status, frequency and channel
- Mute function
-Durable metal diecast housing
- Operation via 2 x 1.5 V batteries (type AA), not included
- License-free and approved in large parts of the EU (please check Duplex Gap on a country-by-country basis)
Type |
Electret boundary microphone |
Directivity Pattern |
Semi-cardioid |
Carrier Frequency Range |
UHF 823-832 and 829-832 MHz |
Switching bandwidth |
11 MHz |
Deviation |
± 45 kHz |
Modulation |
FM |
Frequency stability |
± 0.0005 % |
Frequency response |
50-17000 Hz |
Dynamic range |
50-17000 Hz |
RF power output |
10 mW |
Coverage |
60 m (with line-of-sight) |
Power supply |
2 x 1.5 V battery, type AA |
Current consumption |
approx. 90 mA |
Battery life |
approx. 10 hours |
Dimensions |
119 x 110 x 41 mm |
Weight |
516 g |
